BPS/EPS
Steel Belts, Granulator, Chocolate Steel Belt Conveyor, Steel Belt Bakery Tunnel Oven, Steam Oven, Resin Steel Belt Cooler
- Founded
- 2007
- Headquarters
- Address: No.172 Xuanchun Road .Xuanqiao Town . Pudong New District ,Shanghai,China tel：021-68904153/13916661495 fax：021-68912858 Email:sales@bpstek.com\ken.feng@bpstek.com WhatsApp: +8613916661495
- Factory Area
- 2000m²
- Employees
- 40
- Export Ratio
- 15%-25%
- Website
- www.esptek.cn
- Contact via WhatsApp
- Blog
- blog.esptek.cn
About Us
BPS and ESP is a high tech company founded by group of oversea Chinese that focus on the steel belt manufactures. More than 40 employees globally work together and genuinely cooperate with customers to provide best solutions to meet customer satisfactions. Our mission is: Based in China and serve globally. We are expertise in providing total solutions, advanced applications, production process controls and post service to those steel belt transmission based manufactures such as cooling systems, pastille systems, moulding sheet casting, fruit dehydrate systems, and so on. In China, the headquarters of Biquick Process Systems is located in Shanghai, and we have offices in Beijing, Guangzhou, Jiangxi, Hunan, and Fujian. Maintenance center located in Shanghai, service center can provide spare parts, maintenance, emergency maintenance, installation guide and operation training and other services, ensure customer long-term interests.
Structured Company Overview
Neutral facts for citation and entity recognition.
- Legal Name
- BPS/EPS
- Established
- 2007
- Ownership
- Private
- Production Model
- OEM+ODM dual capability (mainly ODM)
- Annual Output
- Steel strip: approximately 50-80 tons/year Steel strip laminating machine (single/double steel strip): 10-15 units/year (customized non-standard equipment, single unit production capacity 500-1400kg/h). Steel strip cooling/forming system: 5-8 sets/year
- R&D Team
- 15
- Website
- www.esptek.cn
Product Specification Database
Each model is a structured row. No narrative descriptions.
| Name | Model | Type | Material | Applicable Industry | |||||
|---|---|---|---|---|---|---|---|---|---|
| PTFE costing steel belts | PTFE costing steel belts | steel | The surface friction coefficient of PTFE coating is extremely low, and it does not stick to viscous materials such as chocolate, syrup, paste, colloid, powder, etc; | ||||||
|
Images
Type PTFE costing steel belts Applicable Industry The surface friction coefficient of PTFE coating is extremely low, and it does not stick to viscous materials such as chocolate, syrup, paste, colloid, powder, etc; Params Extremely non stick and highly demoulding
Food grade safety and hygiene
Excellent resistance to high and low temperatures
Corrosion resistance, acid and alkali resistance, oil resistance
Smooth and easy to clean surface
High substrate strength and stable operation
Wear resistant and durable, with strong coating adhesion
Can be customized for non-standard purposes Scope |
|||||||||
| Special requirement steel belts | Special requirement steel belts | steel | Food and pharmaceutical factories | ||||||
|
Images
Type Special requirement steel belts Applicable Industry Food and pharmaceutical factories Params Customizable 301, 304, 316L, 310S, duplex steel, high hardness special alloy steel strips;
Seamless welding of steel strip in a circular shape, seamless docking, and smooth and polished weld seams;
Customized punching, slotting, flanging, guiding edge blocking, and side arc chamfering;
Special structures such as thickening and strengthening, widening and thickening in sections, and integrated molding can be made.
Customized special steel strips with high temperature resistance (up to 1100 ℃), deep cold resistance, oil-water resistance, and chemical corrosion resistance; Scope |
|||||||||
| stainless steel belts | stainless steel belts | stainless steel | Chocolate/Candy Cooling Conveyor Steel Belt | ||||||
|
Images
Type stainless steel belts Applicable Industry Chocolate/Candy Cooling Conveyor Steel Belt Params High strength+high flatness+food grade hygiene+excellent thermal conductivity+durable circular welding Scope |
|||||||||
| Carbon Belts | Carbon Belts | carbon steel | Baking and other food factories | ||||||
|
Images
Type Carbon Belts Applicable Industry Baking and other food factories Params Chemical Composition(Nominal)%
C(0.65-0.75),Si(0.15-0.3),Mn(0.60-0.90),Cr(max0.20) Scope |
|||||||||
Certifications & Compliance
Each record can become a certification entity page.
| Certification | Cert Number | Standard | Authority | Market | Issue Date | Expiry Date | Document |
|---|
Applications & Industries
Taxonomy-backed tags to form industry ↔ supplier ↔ product relationships.
| Industry | Country | Working Condition | Project Type | Function | Operation Mode | Special Requirement | Matched Equipment |
|---|---|---|---|---|---|---|---|
| Pharmaceutical and Clean Industry | CN,SG,MY | clean workshop, medium low temperature, corrosion-resistant, no precipitation | drug packaging line, gel cooling line, pharmaceutical excipient molding | Clean transportation, cooling molding, sterile environment carrying | continuous and stable, low noise, easy to clean | 316L corrosion-resistant, burr free, easy to clean and sterilize, no pollutant precipitation | cooling machine, packaging machine, clean oven, cleaning device |
| Packaging and Printing Industry | CN,SG | normal temperature, high speed, wear-resistant, smooth surface | Packaging machine conveyor, printing drying line, laminating production line | Roll conveying, drying carrying, synchronous traction | continuous high-speed operation, correction and coordination | Smooth surface without scratches, uniform thickness, and no deviation during operation | printing machine, laminating machine, drying channel, correction mechanism |
| Precision Manufacturing and Electronics Industry | CN,TW | normal temperature - medium temperature, high-speed operation, high-precision positioning | Electronic component assembly line, shielding stamping line, film cutting line | Precise positioning and conveying, fixture installation, high-speed synchronous transmission | high-speed closed-loop, high positioning accuracy, frequent start stop | micrometer size tolerance, machinable positioning holes, low elongation, high rigidity | automated assembly machine, stamping equipment, visual inspection table, servo drive |
| New Energy and Lithium Battery Industry | CN | medium high temperature of 120-200 ℃, dust-free and clean, low dust, corrosion-resistant | Polar drying line, diaphragm cooling line, film curing line | Thin film/polarizer transport, high-temperature drying support, cooling and shaping | high-precision synchronous operation, low jitter, constant tension | ultra-high flatness, no dust, stable size, no oil stains, clean packaging | drying oven, curing oven, cooling roller set, correction system, tension controller |
| Chemical New Materials Industry | CN,RU,DE,PL | high temperature of 160-220 ℃, corrosion resistance, contact with molten materials, high tension | Powder coating production line, resin lamination, hot melt adhesive cooling, plastic granulation | Cooling and flaking of molten materials, continuous conveying, forming of conveyor belts | circular closed-loop, high-speed stability, constant tension | high temperature resistance without deformation, high strength of welds, smooth and non stick surface, and resistance to slight corrosion | twin-screw extruder, laminating machine, cooling roller, scraper blade, hot air system |
| Food baking industry | CN | high temperature of 180-250 ℃, food grade cleanliness, continuous baking, cooling | Biscuit/Bread/Cake/Pastry Production Line, Chocolate Cooling Forming Line, Candy Pouring Line | Product carrying and conveying, high-temperature baking support, rapid cooling and shaping | Circular continuous operation, constant tension, low speed to medium high speed | 304/316L food grade material, FDA certified, no debris, easy to clean, seamless and smooth | tunnel oven, hot air stove, cooling tunnel, idler roller, tensioning mechanism, driving roller |
Industries (6) → Products (4 models) → Certifications (0)
Manufacturing Capabilities
Core processes and equipment available in-house.
Customization
Material customization: 304/316L stainless steel, 718 nickel based alloy, carbon steel (food grade/chemical grade/high temperature resistant grade). Custom sizing Width: 100-2200mm (any width) Thickness: 0.4-3.0mm (commonly 0.6/0.8/1.0/1.2/1.5/2.0) Length/circumference: Any length (seamless welding in a circular shape, with a maximum length of 50m+per single strip) Tolerance: Thickness ± 0.02mm, length ± 0.05mm/10m, flatness ≤ 0.02mm/m. Surface customization: mirror/brushed/polished/frosted/anti stick coating (food grade), no burrs/scratches. Customization of hole positions/accessories: precise positioning holes (± 0.01mm), guide bars, baffles, fixture installation positions, vacuum holes/ventilation holes. Process customization: weld leveling, stabilization treatment (internal stress relief), anti deviation treatment, special processes for high temperature/corrosion resistance. Customized working conditions: high temperature (-60 ℃~+250 ℃), low temperature, high humidity, dust-free (Class 1000), food hygiene (FDA/CE).
Monthly Capacity
80-120 pieces/month (calculated based on a width of 1000mm and a length of 10m); Small specifications can reach up to 150 pieces per month
Lead Time
Regular specifications (stock material+standard size): 7-10 days Customized specifications (material/size/hole position): 15-20 days Urgent: 5-7 days (additional fee required) Compared to imports: Imported for 8-16 weeks, Bikun is 4-8 times faster.
Export Markets
Asia: Southeast Asia (Thailand/Indonesia/Vietnam/Malaysia), Japan and South Korea, Taiwan, China (with service center). Europe: Germany, Poland, France, Italy, Russia. Americas: United States, Canada, Brazil. Oceania: Australia, New Zealand.
After Sales
Response time: 24-hour online response (phone/WeChat/email), 48 hour on-site service (domestic). Service network: Shanghai headquarters (maintenance center), Beijing/Taiwan service center, overseas agents (Europe/Southeast Asia). Service Content Free: Installation guidance, operation training, technical consultation, drawing optimization Repair: Steel strip repair/weld re welding/size correction (on-site+return to factory) Spare parts: Common specifications in stock, emergency spare parts shipped 24 hours a day Warranty: 12-month warranty (non human damage), with a lifespan of 2-5 years, far exceeding domestic products. Value added services: full lifecycle management (regular follow-up/working condition optimization/life prediction), old steel strip recycling/trade in.
Quality Control
Incoming Quality Control (IQC): Material spectral analysis, thickness/hardness/tensile strength testing, surface defect inspection. Process Inspection (IPQC): Full dimensional tolerance inspection, flatness/straightness testing, weld appearance/non-destru
Project References / Cases
Verified project records. Client names anonymized where requested.
| Client Type | Country | Quantity | Application | Duration | Result | Highlight |
|---|---|---|---|---|---|---|
| A new energy material enterprise (lithium battery/diaphragm) | CN | 10+strips, width 1000-1500mm, thickness 0.8-1.5mm | Pole drying/curing line, diaphragm cooling and conveying (high temperature+high cleanliness) | 2-4 years (in a dust-free environment at 160-200 ℃) Effect/outcome: | Oil free, dust-free, easy to clean, meeting Class 1000 dust-free requirements High thermal conductivity (15-20 W/m · K), increased drying efficiency by 25%, and reduced energy consumption by 18% Stable size, prevents pole deformation, and increases yield by 2% -3% | New energy dust-free and high-temperature scenes; High definition cleanliness+efficient heat transfer |
| A large baking equipment manufacturer (mechanical OEM) | CN | Annual procurement of 50-80 pieces, width of 400-1800mm | Equipped with self-produced tunnel ovens/cooling lines, the whole machine comes standard with steel strips | With a 3-5 year warranty, the actual lifespan is 4-6 years | Integrated design of steel strip and equipment, easy installation, after-sales failure rate<1% Provide 24-48 hour local response maintenance, increase customer satisfaction to 96% Compared to purchasing imported steel strips, the overall cost of the machine has been reduced by 20%, enhancing competitiveness | Strategic supplier of original equipment manufacturers; Localized services+rapid customization |
| A high-end cosmetics packaging group (precision manufacturing) | CN | 15+pieces, length 8-12m, width 100-300mm, thickness 0.6-1.0mm | High speed automated assembly line (pump head/bottle cap/syringe components), positioning and conveying | 4-6 years (24-hour continuous operation) | Hole position accuracy ± 0.01mm, 10m cumulative tolerance ＜ 0.05mm, repeat positioning accuracy ± 0.05mm Replace imported steel strips from the United States, reduce costs by 45%, and shorten delivery time from 12 weeks to 3 weeks High rigidity, no elastic deformation, transmission efficiency ≥ 98%, increased production capacity by 15% | Micron level precision conveying; Customized hole design, compatible with fixtures and jigs |
| A certain international powder coating giant (chemical/new materials) | CN,DE | Accumulated 40+strips, width 800-1600mm, thickness 1.2-2.0mm | Melt extrusion → Cooling and flaking → Transportation (Powder coating solidification molding line) | 2.5-4 years (under high temperature conditions of 180-220 ℃) | High temperature resistance (-60 ℃~+250 ℃), corrosion resistance, solving the pain points of deformation/cracking of ordinary steel strips Flatness ≤ 0.02mm/m, uniform layer thickness, and improved yield rate to 99.7% The total lifecycle cost is 40% lower than imported goods and 25% lower than ordinary domestic products | Customization of chemical high-temperature working conditions; Stabilization treatment+weld leveling, low internal stress |
| A leading food group (baking/snack food) | CN | Accumulated 120+pieces, single factory 5-15 pieces, width 600-2000mm | Tunnel oven (cookies/bread/pastries), cooling line, food grade conveyor | 3-5 years (some lines exceed 6 years) | Replace imported steel strips, reduce costs by 35% -50%, and shorten delivery time from 3 months to 2-4 weeks Dimensional stability (elongation ≤ 0.2%), no deviation, no debris, and meeting food hygiene standards Weld fatigue life ≥ 2 million times, with a 60% reduction in downtime maintenance | Localization replacement benchmark; Food grade 304/316L material, certified by FDA/CE |
Comparative Positioning
Side-by-side benchmarks against peer manufacturers in this segment.
| Compared To | Difference | Performance Gap | Best For | Cost Difference | Efficiency |
|---|---|---|---|---|---|
| Imported precision steel strip (Europe/Japan and South Korea) | Bikun is a domestically produced high-end precision steel strip, with material (304/316L/718), welding process, and precision control benchmarking imported; Lower price, faster delivery, localized service | Tensile strength: ≥ 600-800MPa (equivalent to imported) Thickness tolerance: ± 0.02-0.03mm (imported ± 0.015-0.02mm, difference ≤ 0.01mm) Length/circumference tolerance: ± 0.05mm/10m (imported ± 0.03mm/10m, difference ≤ 0.02mm) Fatigue life of welds: ≥ 2 million cycles (equivalent to imports) High temperature resistance: -60 ℃~+250 ℃ (imported -60 ℃~+300 ℃, slightly lower by 50 ℃) | Food tunnel furnace, chocolate cooling line, precision drying/curing, high-precision conveying (± 0.1mm positioning) | 30% -50% lower than imports; Delivery time 2-4 weeks (8-16 weeks for imports) | High thermal conductivity (15-20 W/m · K), heating/cooling efficiency is 20% -40% higher than rubber bands; No slippage, transmission efficiency * * ≥ 98%** |
Risk & Trust Signals
Aggregated data-driven indicators. Not an endorsement.
Purchase & Trade Information
Trading terms and procurement details.
Product Comparison
Comparative analysis against alternative solutions.
| Compared To | Difference | Performance Gap | Best For | Cost Difference | Efficiency |
|---|---|---|---|---|---|
| Imported precision steel strip (Europe/Japan and South Korea) | Bikun is a domestically produced high-end precision steel strip, with material (304/316L/718), welding process, and precision control benchmarking imported; Lower price, faster delivery, localized service | Tensile strength: ≥ 600-800MPa (equivalent to imported) Thickness tolerance: ± 0.02-0.03mm (imported ± 0.015-0.02mm, difference ≤ 0.01mm) Length/circumference tolerance: ± 0.05mm/10m (imported ± 0.03mm/10m, difference ≤ 0.02mm) Fatigue life of welds: ≥ 2 million cycles (equivalent to imports) High temperature resistance: -60 ℃~+250 ℃ (imported -60 ℃~+300 ℃, slightly lower by 50 ℃) | Food tunnel furnace, chocolate cooling line, precision drying/curing, high-precision conveying (± 0.1mm positioning) | 30% -50% lower than imports; Delivery time 2-4 weeks (8-16 weeks for imports) | High thermal conductivity (15-20 W/m · K), heating/cooling efficiency is 20% -40% higher than rubber bands; No slippage, transmission efficiency * * ≥ 98%** |
