About CINON

CINON Composites specializes in fiberglass reinforcements and lightweight core materials for marine, transportation, wind energy, industrial, and aerospace composite applications.
Our product range includes fiberglass fabrics, biaxial fabrics, PET foam core, PVC foam core, PMI foam core, Core Mat, PP honeycomb, and aramid honeycomb.
We help composite manufacturers reduce weight, improve structural stiffness, optimize vacuum infusion processes, and lower total manufacturing costs.
CINON materials are widely used in boat building, yacht construction, wind turbine blades, transportation panels, UAV structures, and industrial composite components.
🎓
World-Class Team
Graduates from top universities worldwide
🔬
Advanced R&D
Self-developed
🤖
Innovation Focus
Multiple innovative technologies

Our Products

View All Products →
PP honeycomb sheet

PP honeycomb sheet

Model: Thermoplastic Honeycomb Core
Parameters: Material: Polypropylene (PP)
Thickness: from 5-100mm
Cell Size:6mm /8mm/10mm/12mm
Density:70/80 kg/m³

Standard Size:
1220×2440 mm
Customized Sizes Available

Surface Options:
PP Nonwoven
Fiberglass Skin

Processing:
Cutting
CNC Machining
Lamination
Thermoforming

Nomex Honeycomb

Nomex Honeycomb

Model: Aramid honeycomb core
Parameters: Cell size：1.83 , 2.75 , 3.67 , 5.5mm
Density：32,40,48,64,80,96,128Kg/m³
Supply status：cutting strip,fixed telephone block,slice cut block
Dimension：2440*1220mm
Mechanical properties：0.43~5.52mpa
Working temperature：-60 ~ 180℃
Storage condition：store under normal temperature and dry condition

PMI foam core

PMI foam core

Model: PMI foam core
Parameters: Density:40kg/m³,50kg/m³,80kg/m³,100kg/m³,130kg/m³,

Recyclable Foam Core

Recyclable Foam Core

Model: PET foam core
Parameters: Density:80kg/m³,100kg/m³,120kg/m³,150kg/m³,200kg/m³,250kg/m³/320kg/m3

PVC foam core

PVC foam core

Model: PVC foam core
Parameters: Density:45kg/m³,50kg/m³,60kg/m³,80kg/m³,100kg/m³,130kg/m³,200kg/m³,250kg/m³,300kg/m³
Thickness: 1–80 mm
Surface Options:Plain/Grooved/Perforated/Scrim-backed
Processing Methods:Vacuum Infusion，RTM，Hand Lay-up，Prepreg，VARTM

Infusion Core Material

Infusion Core Material

Model: CX Core Material
Parameters: Thickness:1.5mm/2mm/3mm
Roll length:70m/60m/40m
width:1.27m
Max. Process Temperature:180℃
Dry weight:120g/㎡，150g/㎡，220g/㎡

General Purpose Core Material

General Purpose Core Material

Model: CS Core Material
Parameters: Thickness:2mm/3mm
Roll length:80m/50m
width:1.27m
Max. Process Temperature:170℃
Dry weight:130g/㎡，170g/㎡

Lightweight Infusion Core

Lightweight Infusion Core

Model: CT Core Material
Parameters: Thickness:1.5mm/2mm/3mm
Roll length:120m/80m/50m
width:1.27m
Max. Process Temperature:180℃
Dry weight:90g/㎡，120g/㎡，160g/㎡

Structural Core Material

Structural Core Material

Model: CM core mat
Parameters: Thickness:1.5mm/2mm/3mm/4mm/5mm/6mm
Roll length:80m/80m/50m/40m/30m/25m
width:1.27m
Max. Process Temperature:175℃
Dry weight:125g/㎡，150g/㎡，190g/㎡，260g/㎡，340g/㎡，360g/㎡

Fiberglass fabric

Fiberglass fabric

Model: Light Weight Fiberglass Cloth
Parameters: 1.Glass Type:E-Fiberglass
2.Model:EW
3.Weave:Plain Woven
4.Width:1000mm,1010mm
5.weight:25-400g/m2

Structural Composite Reinforcement

Structural Composite Reinforcement

Model: Multiaixal Fiberglass Fabrics
Parameters: Material:Fiberglass
Structure Design:Unidirectional:0° or 90° direction
Biaxial:0°/90° direction or +45°/-45° directions
Triaxial:+45°/0°/-45°direction or +45°/90°/-45° directions
Quadriaxial:in 0°/90°/-45°/+45° directions
Weight (g/m2):400~1500gsm
combustible matter(%):2.0%-8.0%
Moisture Content:Less than 0.2%
Application:Used in vacuum, hand layup, extrusion, RTM and other formed products, such as ship hulls, wind turbine blades, automotive
components, sports equipment, large containers

Company Gallery

CINON Composites headquarters supporting global customers in fiberglass reinforcements and lightweight core materials for marine, wind energy, transportation, and industrial composite applications.
CINON Composites headquarters supporting global customers in fiberglass reinforcements and lightweight core materials for marine, wind energy, transportation, and industrial composite applications.
Manufacturing facility for fiberglass fabrics, multiaxial reinforcements, PET foam core, PVC foam core, Core Mat, and honeycomb core materials used in lightweight composite structures.
Manufacturing facility for fiberglass fabrics, multiaxial reinforcements, PET foam core, PVC foam core, Core Mat, and honeycomb core materials used in lightweight composite structures.
Inventory management and export preparation center supporting global delivery of fiberglass reinforcements and composite core materials to Europe, North America, and Asia-Pacific markets.
Inventory management and export preparation center supporting global delivery of fiberglass reinforcements and composite core materials to Europe, North America, and Asia-Pacific markets.
Closed-cell PVC foam core manufacturing for sandwich panel construction, yacht hulls, wind turbine blades, and industrial composite applications.
Closed-cell PVC foam core manufacturing for sandwich panel construction, yacht hulls, wind turbine blades, and industrial composite applications.
Core Mat manufacturing process for lightweight sandwich structures, vacuum infusion applications, and marine composite construction. Alternative solution to Soric core materials.
Core Mat manufacturing process for lightweight sandwich structures, vacuum infusion applications, and marine composite construction. Alternative solution to Soric core materials.
Export logistics and container loading process ensuring reliable worldwide delivery of composite reinforcement fabrics and lightweight core materials.
Export logistics and container loading process ensuring reliable worldwide delivery of composite reinforcement fabrics and lightweight core materials.

Certifications & Awards

IS0 9001:2015
IS0 9001:2015
IS0 45001:2018
IS0 45001:2018
IS0 14001:2015
IS0 14001:2015

Success Stories & Case Studies

Sports Equipment Manufacturers

Sports Equipment Manufacturers

Weight Reduction
Performance Improvement
High Buoyancy & Impact Resistance

📍 Location: TH 📦 Quantity: container ordres
UAV Manufacturers

UAV Manufacturers

Ultra-Lightweight Structures
High Stiffness
High Temperature Resistance
Fatigue Resistance, Low Density

📍 Location: DE 📦 Quantity: 10pallets
Transportation Panel Manufacturers

Transportation Panel Manufacturers

Lightweighting, Improved Corrosion Resistance
Good Adhesion With Core Material

📍 Location: MX 📦 Quantity: container orders
RV Manufacturers

RV Manufacturers

it'g glossy for surface treatment, and uniformity of thickness
Low Weight & Anti-UV Performance

📍 Location: US 📦 Quantity: 5 pallets
Marine & Yacht Builders

Marine & Yacht Builders

Smooth Surface
Easy Wet-Out
Better Finish
Material Selection

📍 Location: AU 📦 Quantity: container orders
Composite Materials Distributor

Composite Materials Distributor

good feedback for products, and reorder every month
OEM label for customer

📍 Location: CZ 📦 Quantity: Container Orders
Composite Material Distributor

Composite Material Distributor

Alternative Supply Solution
Fast lead time & reliable export logistics

📍 Location: GB 📦 Quantity: Sample Evaluation + Commercial Supply
Composite Material Distributor

Composite Material Distributor

good sale in the local, and repeat orders every month
OEM logo for customer

📍 Location: PL 📦 Quantity: container order
