15.6W 24V 0.65A Korea Plug Power Adapter With KC And UL Approvals

Quantity:
SKU: 3176657684
Model: SK01T

{{ variable.name }}

{{ value.name }}
simsukian Power Adapter
Enter Shop
Product Details
SK01T Series · Korea Plug

15.6W 24V 0.65A Korea Plug Power Adapter With KC And UL Approvals

Wall-mount AC to DC power adapter delivering a stable 24V 0.65A output from a universal 100-240V 50/60Hz input. Moulded in fire-retardant PC with short-circuit, overvoltage and overcurrent protection.

24V 0.65A Output KC / KCC DOE / ERP / CEC-VI Fire-Retardant PC
24V 0.65A SK01T power adapter with Korea plug shown from the front

Product Summary

The SK01T is a wall-mount AC to DC power adapter built for 24V equipment drawing up to 0.65A, giving a 15.6W output. Its universal AC 100-240V 50/60Hz input allows one model to serve buyers across regions, while the Korea AC plug matches Korean wall outlets. The adapter is housed in fire-retardant PC and includes short-circuit, overvoltage and overcurrent protection. Real certificates covering KC, KCC, UL, ETL, FCC, SAA, PSE, CCC, CQC, CE-LVD, CE-EMC and RoHS requirements support import compliance work. OEM and ODM customization is available for buyers who need adjusted output or branding.

Key Features

24V 0.65A Stable Output

Fixed 24V output at 0.65A, 15.6W output power, matched to 24V devices that need a consistent DC rail.

Universal 100-240V Input

AC 100-240V 50/60Hz input means the same adapter model can be stocked for multiple regions instead of region-locked SKUs.

Korea AC Plug With KC / KCC

The Korea plug configuration and KC, KCC certificates make this model directly relevant to Korean market import and retail requirements.

Triple Protection Circuits

Short-circuit, overvoltage and overcurrent protection are stated in the design, reducing field failure risk in end products.

Fire-Retardant PC Housing

Fire-retardant PC material for the housing, supporting safety-oriented buyer requirements for enclosure materials.

Efficiency And Safety Compliance

Energy efficiency built to DOE / ERP / CEC-VI standards, with safety standards IEC62368 / IEC64558 / IEC60347.

Technical Specifications

ModelSK01T
Product Type18W power adapter, wall-mount
Output Voltage24V
Output Current0.65A
Output Power15.6W
InputAC 100-240V 50/60Hz
AC PlugKorea
Color OptionsBlack, white, customized
Energy EfficiencyAccording to DOE / ERP / CEC-VI standard
Safety StandardsIEC62368 / IEC64558 / IEC60347
CertificatesKC, KCC, UL, ETL, FCC, SAA, PSE, CCC, CQC, CE-LVD, CE-EMC, RoHS requirements
Housing MaterialFire-retardant PC

Models and Options

This variant is the SK01T 24V 0.65A wall-mount adapter with the Korea AC plug, supplied in white or black housing. Buyers who need a different output configuration can request customized output under the OEM and ODM service. Simsukian manufactures switching power supplies, chargers and power adapters from 3W to 240W, so related ratings outside the SK01T can be discussed against the same compliance documentation set.

Materials and Structure

The enclosure is moulded in fire-retardant PC, chosen for enclosure safety rather than appearance alone. The adapter uses a wall-mount structure that plugs directly into the outlet, so no separate power cord or desk space is needed in installation. Inside, the short-circuit, overvoltage and overcurrent protection described for this model support stable behaviour when the load or mains supply is abnormal.

Applications

This 24V 0.65A adapter is positioned for electronics and equipment projects in the following sectors:

Manufacturing equipment Home appliances IT products LED lighting Electronics

Customization

Simsukian offers OEM and ODM support, including customized output, customized housing color (black, white or custom) and the documentation set needed for the destination market. The company holds ISO 9001:2015 and ISO 14001:2015 certification and more than 90 national patents, with a 30-engineer R&D team behind turn-key customization work. Buyers can send their target voltage, current, plug and certification requirements for review.

FAQ

What is the output rating of the SK01T?

It provides a 24V 0.65A DC output, giving 15.6W output power, from an AC 100-240V 50/60Hz input.

Which AC plug does this model use?

The SK01T in this configuration uses the Korea AC plug and carries KC and KCC certificates.

Which certificates and standards are available?

KC, KCC, UL, ETL, FCC, SAA, PSE, CCC, CQC, CE-LVD, CE-EMC and RoHS requirements, with safety standards IEC62368 / IEC64558 / IEC60347 and energy efficiency to DOE / ERP / CEC-VI.

What material is the housing made of?

The housing is moulded in fire-retardant PC.

What protection features are built in?

Short-circuit protection, overvoltage protection and overcurrent protection are stated for this adapter.

Can the output or color be customized?

Yes. Customized output is offered, and color options are black, white or customized, supported by OEM and ODM services.

How do I request a quotation or technical documents?

Contact the sales team through the details in the inquiry section below with your required output, plug, color and certification needs.

Inquiry Information

Shenzhen Simsukian Electronics Technology Co., Ltd — founded 1996, ISO 9001:2015 and ISO 14001:2015 certified, exporting to the EU, USA, AUS, JP, Korea and UK.

  • Contact: Abby
  • Email: 8042@simsukian.com
  • Tel / WhatsApp: +86 15361658306
  • Address: #27, Guifu Rd, Guanlan, Longhua, Shenzhen, China. Zip code 518110
  • Website: www.simsukianpower.com

Please include the target voltage, current, plug type, housing color and required certificates so the team can reply with the matching configuration.
