This auto-clean all-in-one solar street light integrates a 100W monocrystalline solar panel, 80W LED module with 200 lm/W efficacy, and a 45Ah LiFePO4 battery in a single die-cast aluminum housing. Designed for continuous operation over 3-5 rainy days with 12 hours per night, it features light/time/microwave sensor controls and an automatic cleaning system to maintain performance. With a recommended installation height of 7-8m and pole diameter of 60-65mm, it suits municipal and public road lighting projects.
Key Features
Auto-Clean System – Automatic cleaning maintains solar panel efficiency without manual maintenance.
High-Efficiency Solar Panel – 100W DC18V monocrystalline panel maximizes energy capture.
Long-Lasting Battery – LiFePO4 45Ah 12.8V battery provides 3-5 rainy days of backup.
Smart Sensing – Light/time/microwave sensor control adapts to occupancy and ambient light.
Energy-Efficient LED – 80W LED with 200 lm/W output reduces energy consumption.
Durable Housing – Die-cast aluminum housing with IP67 protection for outdoor use.
Technical Specifications
Parameter
Value
Model
ML-CL-80
Solar Panel
100W DC18V (Monocrystalline)
LED Power
80W (5050 San'An LED, 200 lm/W)
Battery
LiFePO4 45Ah × 12.8V
Controller
12V15A
CCT
6000K (3500-6000K customizable)
Work Time
12 hours/night, 3-5 rainy days
Control Mode
Light/Time/Microwave sensor
Installation Height
7-8m
Installation Distance
20-30m
Pole Diameter
60-65mm
Housing Material
Die-cast Aluminum
Lamp Size
1543×373×50 mm
Time Dimming
100% 4h / 70% 4h / 30% 4h
Models and Options
The ML-CL-80 is available with customizable CCT (3500K-6000K) to suit different lighting preferences. Other all-in-one solar street light models from the same series include foldable versions (Palm Series) with 40W/64W/100W/120W options, which are covered under CB, Rosh, ISO, IP67, FCC, and CE certifications. Please contact us for specific configuration requirements.
Materials and Structure
The lamp housing is constructed from die-cast aluminum, ensuring high durability and effective heat dissipation. The integrated design combines the solar panel, LED module, battery, and controller into one streamlined unit, reducing installation complexity and improving aesthetic appeal for modern road lighting.
Applications
Ideal for municipal and public facilities, road lighting, energy conservation and environmental protection projects. The robust design and smart controls make it suitable for highways, residential streets, parking lots, and remote areas where reliable autonomous lighting is essential.
Customization
We offer customization of CCT from 3500K to 6000K to match project requirements. For special needs such as different pole diameters, custom dimming schedules, or specific battery capacities, please contact our engineering team with your project details.
FAQ
How does the auto-clean system work?
The auto-clean system periodically cleans the solar panel surface to remove dust and debris, ensuring optimal solar energy absorption and consistent performance without manual intervention.
What is the battery capacity and backup time?
The integrated LiFePO4 battery has a capacity of 45Ah at 12.8V, providing sufficient energy for 12 hours of lighting per night and up to 3-5 continuous rainy days, depending on location and usage.
Can the color temperature be customized?
Yes, the standard CCT is 6000K, but it can be customized to any value between 3500K and 6000K according to your project's lighting requirements.
What control modes are available?
The light supports light control, time control, and microwave sensor control. You can choose the mode that best fits your application to maximize energy savings and operational efficiency.
What is the recommended installation height and spacing?
For optimal lighting coverage, the recommended installation height is 7-8 meters, with spacing between lights of 20-30 meters. The pole diameter should be 60-65mm to ensure a secure fit.
What is the lamp size and weight?
The lamp dimensions are 1543×373×50 mm. Detailed weight information is available upon request.
What certifications does the product hold?
While this specific model's certifications are not listed, our Palm Series foldable all-in-one solar street lights have CB, Rosh, ISO9001:2015, IP67, FCC, and CE certifications. For certifications related to model ML-CL-80, please contact our sales team.
Inquiry Information
For pricing, MOQ, and delivery details, please contact our sales team.
