Product Summary
Designed for the Australian market, this EDUN 108 Series sliding door meets AS2047 certification for structural integrity and weather resistance. With high wind load resistance and low U-value, it is an energy-efficient solution for residential and commercial buildings.
Key Features
AS2047 Certified - Compliant with Australian standard for windows and doors.
Thermal Break Technology - 65mm thermal break reduces heat transfer.
Triple Glazing - 6+12+6+12+6mm Low-E glass for superior insulation.
Wind Load Resistance - Withstands 5440 Pa, suitable for cyclonic areas.
Sound Insulation - 37 dB reduction for quiet interiors.
Technical Specifications
| Parameter | Value |
|---|
| Profile Thickness | 2.0 mm |
| Glass Spec | 6+12+6+12+6 mm (optional) |
| Wind Load Resistance | 5440 Pa |
| Sound Insulation | 37 dB |
| Water Tightness | 720 Pa |
| U-value | 1.2 W/m²·K |
| Certification | AS2047-2014 |
Models and Options
Available in different sizes and configurations, with options for glass type, frame color, and hardware. Customization is available to fit specific project needs.
Materials and Structure
Uses Xingfa aluminum alloy profiles and KIN LONG hardware. The thermal break is made of 65mm polyamide strips, and insulation foam is placed to enhance thermal performance. Low-E triple glazing ensures high insulation.
Applications
High-end villas, residential complexes, commercial buildings, and renovation projects across Australia. Suitable for coastal and bushfire-prone areas due to its structural strength.
Customization
We can adjust dimensions, glazing specs, hardware, and colors. Our team works closely with clients to meet design and performance requirements.
Case Study
An Australian villa project used 77㎡ of this sliding door, demonstrating excellent thermal performance and aesthetic appeal. The door has been in use for over 20 years.
FAQ
Is the EDUN 108 sliding door available in custom sizes?
Yes, we can manufacture any size to suit your project requirements.
Does this door meet Australian energy efficiency regulations?
It is designed to comply with AS2047 and has a low U-value for energy efficiency.
What glass options are available?
Standard is 6+12+6+12+6mm Low-E triple glazing, but other configurations can be provided.
Can the door withstand severe weather conditions?
With a wind load resistance of 5440 Pa, it is suitable for high wind and storm-prone regions.
How is the thermal break implemented?
A 65mm thermal break strip is used to reduce thermal bridging.
Do you provide installation instructions?
Yes, we provide detailed installation guides and remote support.
What is the minimum order quantity?
Please contact us for MOQ details as it varies by project.
Can we request samples?
Samples can be provided upon request for evaluation.
Inquiry Information
For further information, email info@edunwindows.com or call +86 18988630128.
