DR10 High-Temper Deep Drawing Tinplate Coil Matte Black Finish

Quantity:
SKU: 7564826584
Model: DD-UT-DR Series

{{ variable.name }}

{{ value.name }}

DR10 High-Temper Deep Drawing Tinplate Coil Matte Black Finish

Product Summary

The DD-UT-DR Series high-temper DR10 tinplate coil with matte black finish is designed for demanding deep drawing applications requiring maximum hardness and premium appearance. Ultra-thin gauges 0.14-0.17mm with precise tolerances (±0.005mm thickness, ±0.05mm width) ensure reproducibility. The matte black coating offers a sophisticated look for consumer electronics and luxury packaging.

Key Selling Points

  • DR10 maximum temper: Highest hardness grade for resistance to deformation.
  • Matte black premium finish: Aesthetic, non-reflective surface for electronics and cosmetics.
  • Ultra-thin 0.14-0.17mm: Reduces material weight and cost.
  • Extreme deep drawing: No micro-cracking even at maximum temper.
  • Certified quality: ISO9001:2015 and RoHS compliant.

Technical Specifications

ParameterValue
Thickness Range0.14mm, 0.15mm, 0.16mm, 0.17mm
Thickness Tolerance±0.005mm
Width Range4.0mm - 1050mm
Width Tolerance±0.05mm
TemperDR10
Tin Coating Mass1.1/1.1, 2.8/2.8 (equally or differentially coated)
Edge Burr Level≤0.05mm
Surface FinishMatte Black

Models and Options

  • Model: DD-UT-DR10
  • Options: Single or double-sided coating; Matte Black finish.

Materials and Structure

Premium electrolytic tinplate (ETP/DR) or mirror galvanized steel base, coated with matte black finish. The steel structure is optimized for high hardness and deep drawing without defects.

Applications

  • Electronics shielding cases
  • Premium cosmetics hardware
  • Automotive components
  • Advanced packaging (aerosol cans, deep-drawn caps)

Customization

Custom widths, tin coating mass, and surface finishes available. Our team can tailor the product to match your stamping requirements.

Frequently Asked Questions

What is the MOQ?

2 tons or as per sizes.

How precise are the dimensions?

Thickness ±0.005mm, width ±0.05mm.

Can this material withstand deep drawing without cracking?

Yes, our DR10 tinplate is engineered to resist micro-cracking and earing.

What certifications do you hold?

BV ISO9001:2015 and SGS RoHS certification.

Do you offer samples?

Please contact us for sample availability and lead time.

Inquiry Information

Contact Mr. Qing at +86-23-62566629, WhatsApp +86-13594107385, or email info@youngsonmetal.com. We serve global markets with 70% export ratio.

Image Filename and Alt Suggestions

DR10 matte black deep drawing tinplate coil for high-temper applications
