High-Efficiency Wheel Hub Cap Coating Line

Specialized for coating wheel hub caps made from ABS+PC, this line offers a production rate of 1,760 trays per day with a 45-second cycle. The system utilizes robotic spraying and PLC control to deliver consistent quality and efficient operation.

Key Selling Points

Dedicated Design: Tailored for wheel hub caps, ensuring optimal handling and coating.
Fast Cycle Time: 45 seconds per tray enables high daily output of 1,760 trays.
Robotic Application: Robots provide precise coating, minimizing defects and waste.
Cleanroom Compatible: Designed for ISO Class 10,000 environments.
Compliance: Meets ISO9001 and ISO14001 standards.

Technical Specifications

Part Name	Wheel hub caps
Part Material	ABS + PC
Working Days	336 days/year
Daily Working Hours	22 hours/day
Spray Booth Temperature	25 ± 2 °C
Spray Booth Humidity	65 ± 10 % RH
Painting Method	Robotic spraying (off-line mode)
Production Cycle	45 seconds per tray (1,760 trays/day)
Max Tray Size	1350 mm (L) x 900 mm (W) x 200 mm (H)
Equipment Utilization Rate	85%
Factory Dimensions	100 m (L) x 38 m (W) x 5.4 m (H)
Energy Sources	Electricity, natural gas, steam, chilled water

Models and Options

Can be equipped with different tray designs for various hub cap sizes and configurations.

Materials and Structure

Carbon steel structure with stainless steel spraying and piping. Includes flame treatment booth for surface preparation.

Applications

Specifically for wheel hub caps, also suitable for other small plastic parts with similar geometry.

Customization

Customizable jigs and fixtures to hold various hub cap designs, and integration with automated inspection systems.

FAQ

What is the production capacity?

Up to 1,760 trays per day.

Can it handle different cap sizes?

Yes, with adjustable jigs and tray options.

What material can be processed?

ABS+PC is the standard, but other plastics can be accommodated with appropriate pretreatment.

Is it easy to maintain?

The design includes accessible components and easy-to-clean surfaces.

Can we get a trial run?

We offer pre-shipment testing as part of the acceptance procedure.

What are the utility requirements?

Electricity, natural gas, steam, and chilled water are needed.
