SS304 Stainless Mobile Pipeline Compressed Air Dryer PDL Series

Name: "SS304 Stainless Mobile Pipeline Compressed Air Dryer PDL Series"
Rating: 5 (386 reviews)

Quantity:

SKU: 4261835096

Model: PDL Series

BODA GAS

Enter Shop

Product Details

SS304 Stainless Mobile Pipeline Compressed Air Dryer PDL Series

PDL series stainless steel desiccant dryer unit

Portable pipeline air dryer in stainless steel finish

Mobile pipeline specific dryer stainless steel body

Product Summary

This PDL Series dryer is constructed from SS304 stainless steel, offering superior corrosion resistance for aggressive environments such as offshore platforms and chemical plants. It provides the same reliable -40°C dew point and low regeneration loss as the standard carbon steel model, but with enhanced durability and compatibility with demanding process conditions.

Key Selling Points

SS304 stainless steel construction resists corrosion and extends service life in harsh environments.
Qualified dew point of -40°C ensures deep drying for critical pipeline applications.
Low regeneration air loss (≤6%) cuts energy consumption and operating costs.
Container-type design with self-contained power enables easy field deployment and relocation.
PLC control with LCD display provides real-time monitoring and alarm functions.
Customizable to ATEX, ASME, or CE standards meets international project requirements.

Technical Specifications

Parameter	Value
Rated air treatment flow rate	1~300 Nm³/min
Working pressure	0.6~1.6 MPa
Qualified air dew point	-40°C
Inlet temperature	<120°C
Pressure loss	≤0.02 MPa
Residual oil content	<0.01 mg/m³
Regeneration air loss	≤6% or ≤12%
Material	SS304

Models and Options

Available in flow capacities from 1 to 300 Nm³/min within the PDL series. Can be manufactured with ATEX, ASME, or CE compliance on request.

Materials and Structure

All wetted parts are SS304 stainless steel, ensuring high resistance to corrosive media. The container-type structure includes lifting lugs and a self-contained power system for rapid mobilization.

Applications

Offshore platform piping and gas-lift systems
Chemical product transmission pipelines
Oil-field commissioning and wellhead facilities
Power plant instrument air systems

Customization

Custom materials (SS304), ATEX, ASME, and CE certifications are available. Flow rate and control system can be tailored to project specifications.

FAQ

Why choose SS304 stainless steel?

SS304 provides excellent corrosion resistance, making it suitable for offshore and chemical environments.

Can the dryer be used in ATEX zones?

Yes, ATEX certification is available as an option.

What is the typical dew point achievable?

The qualified air dew point is -40°C.

Is the dry weight higher than carbon steel?

SS304 is slightly heavier, but the container design facilitates crane lifting.

What is the minimum order quantity?

MOQ is 1 unit.
