SSAW Spiral Welded Steel Pipe

MESCO supplies SSAW (Spiral Submerged Arc Welded) pipes known for their high strength and structural integrity. Manufactured to ASTM A53 and API 5L standards, these pipes are engineered for infrastructure, piling, and heavy-duty applications. Available in large diameters up to 610mm with wall thicknesses up to 30mm.

Key Selling Points

ASTM A53 / API 5L Standards – Ensures compliance with international quality requirements.
Large Diameter Capability – Up to 610mm OD ideal for high-volume transportation and structural projects.
Superior Weld Strength – Spiral welding provides enhanced resistance to external pressure and bending.
Versatile Grades – Q235B, Gr.B, and X52 meet various strength and toughness needs.
Custom Coatings – Black, galvanized, or 3PE options for extended service life.
Global Export Experience – MESCO has served more than 700 clients in 100+ countries.

Technical Specifications

Product	Welded Steel Pipe
Type	SSAW
Standard	ASTM A53, API 5L
Grade	Q235B, Gr.B, X52
OD	21.3mm – 610mm
WT	1.5mm – 30mm
Length	6m / 12m
Surface	Black, Galvanized, 3PE
Ends	Plain End, Beveled End
Material	Carbon Steel

Models and Options

Available in various sizes and grades; custom end preparations and coatings available.

Materials and Structure

Produced from high-strength carbon steel, SSAW pipes feature a spiral seam that enhances mechanical strength and durability.

Applications

Ideal for infrastructure, piling, water transmission, and structural support in construction and oil & gas sectors.

Customization

We offer tailored sizes, lengths, coatings, and packaging options to meet project specifications.

Case Study

A construction company in Peru ordered 1,700 MT of MESCO welded pipes for building structures. The excellent weld performance and stable dimensions contributed to a cost-effective structural solution, ensuring project quality and safety.

FAQ

What is SSAW pipe?

SSAW stands for Spiral Submerged Arc Welding, a method that creates a strong spiral weld line along the pipe, offering high reliability.

What sizes are available?

We supply SSAW pipes with OD up to 610mm and WT up to 30mm.

Which grades are available?

Common grades include Q235B, Gr.B, and X52.

Can you provide 3PE coated pipes?

Yes, 3PE coating is available to enhance corrosion resistance.

Do you support third-party inspection?

Yes, both third-party and factory inspections are available, and material test reports can be supplied.

What is the payment method?

We accept T/T and L/C at sight, with other terms negotiable.

Inquiry Information

Contact Max: mesco@mescogroup.com.cn | WhatsApp: +86 151-3456-5556

Image 1: SSAW Welded Pipe - Large Diameter - Spiral Seam

Image 2: SSAW Welded Pipe - X52 - Surface Finish
