Servo Hydraulic High Precision Leveling Machine MHTR50 Series
Product Summary
The MHTR50 Series is a servo-hydraulic hybrid drive leveling machine engineered for high-precision straightening of metal plates. Combining German hydraulic technology with advanced CNC control, it delivers micron-level accuracy up to 0.01mm, ensuring superior flatness for demanding applications in new energy, automotive, aerospace, and more.
With a 23-roll configuration and thickness capacity up to 10mm (rated 0.8-5.0mm), the MHTR50 handles a wide range of materials including carbon steel, stainless steel, aluminum, and copper. Its mortise-tenon rigid frame and anti-collapse dynamic compensation system guarantee stability and safety under continuous heavy loads.
Certified to ISO9001:2015 and CE standards, the machine is a import-grade alternative that offers up to 70% energy savings compared to traditional hydraulic levelers, reducing operational costs and environmental impact.
Key Features
- German Hydraulic & CNC Technology: Combines proven hydraulic power with precise CNC control for consistent, repeatable leveling results.
- Servo-Hydraulic Hybrid Drive: Reduces energy consumption by up to 70% compared to traditional hydraulic systems, lowering operating costs.
- Micron-Level Accuracy: Achieves flatness tolerance of ±0.01mm, meeting stringent quality requirements for high-end industries.
- Alloy Rolls Mark-Free: Advanced alloy rolls minimize surface marking, preserving the finish of sensitive materials like mirror-finish sheets.
- Anti-Collapse Dynamic Compensation: Ensures stable operation and prevents plate deflection, enhancing safety and prolonging machine life.
- Mortise-Tenon Rigid Frame: Provides exceptional structural rigidity, reducing vibration and maintaining accuracy even under heavy loads.
Technical Specifications
| Parameter |
Value |
| Width |
600 ~ 2600 mm |
| Rated Thickness |
0.8 ~ 5.0 mm |
| Max Thickness |
10.0 mm |
| Number of Rolls |
23 |
| Speed |
0 ~ 10 m/min |
| Accuracy |
±0.01 mm |
Models and Options
The MHTR50 Series offers customization to meet specific production needs, including:
- Custom width configurations within 600-2600mm
- Optional IoT connectivity for remote monitoring and predictive maintenance
- Integration with uncoilers, laser cutting machines, stamping presses, and robotic arms
- Electric gap adjustment for rapid setup changes
Materials and Structure
The MHTR50 Series handles a variety of materials:
- Carbon steel
- High-strength steel
- Stainless steel
- Aluminum
- Copper
- Mirror-finish sheet
- Thick plate
The machine features a mortise-tenon rigid frame construction, ensuring high structural integrity and long-term stability.
Applications
Ideal for industries such as:
- New energy
- Military
- Heavy industry
- Automotive/Truck
- Construction
- Shipbuilding
- Aerospace
- Metal processing
Typical applications include precision leveling of plates for laser cutting, stamping, welding, and assembly.
Customization
We offer tailored solutions to meet your specific requirements, including custom working widths, integration with existing production lines, and optional features like IoT connectivity and specialized roll materials.
Case Study
Client: Manufacturer in Australia (AU)
Industry: Precision leveling of ceiling panel substrates
Order Value: $100,000
Duration: 3 years
Result: Solved enterprise difficulties, increased profit by 30%
FAQ
Q: What is the accuracy of the MHTR50 Series leveler?
A: The MHTR50 Series achieves micron-level accuracy up to 0.01mm, ensuring high-precision flatness for critical applications.
Q: What materials can the machine process?
A: It handles carbon steel, high-strength steel, stainless steel, aluminum, copper, mirror-finish sheets, and thick plates.
Q: How does the energy saving feature work?
A: The servo-hydraulic hybrid drive reduces energy consumption by up to 70% compared to traditional hydraulic systems.
Q: What certifications does the machine have?
A: The machine is certified to ISO9001:2015 (Quality Management System) and CE (Machinery Directive).
Q: Can the machine be customized for specific widths?
A: Yes, the MHTR50 Series offers customizable width configurations within 600-2600mm.
Q: What is the MOQ?
A: MOQ is 1 unit.
Q: What are the payment terms?
A: 30% deposit, 70% final payment before shipment.
Q: How is the machine delivered?
A: Delivery methods include FOB, CIF, and DAP.
