ZAM Alloy Coated Steel Strip for Corrosion-Resistant Hardware and Automotive Shields

Quantity:
SKU: 6014415629
Model: TP-EC-Series (T1-T5 / DR7-DR10

{{ variable.name }}

{{ value.name }}

ZAM Alloy Coated Steel Strip for Corrosion-Resistant Hardware and Automotive Shields

Our ZAM alloy coated steel strip combines the superior corrosion resistance of Zinc-Aluminum-Magnesium coating with the formability required for hardware and automotive components. Available in a full range of tempers (T1-T5, DR7-DR10) and thicknesses from 0.14mm to 0.55mm, this strip is precision slit to widths of 4.0mm to 1050mm without joints or burrs. The eco-friendly coating system provides excellent paint adhesion and anti-fingerprint options. Ideal for applications demanding long-term durability, such as automotive shields, cable wrapping, and outdoor hardware.

Key Features

  • Superior corrosion resistance: ZAM coating provides self-healing protection at cut edges.
  • Full temper range: T1-T5 and DR7-DR10 for various forming needs.
  • Eco-friendly coating: Single/multi-color lacquer, SGS REACH & RoHS compliant.
  • Precision slitting: Widths from 4.0mm to 1050mm, jointless and burr-free.
  • Flexible coil options: IDs 160-500mm.

Technical Specifications

Base steelCold rolled steel, hot-dip galvanized
CoatingZinc-Aluminum-Magnesium (ZAM) alloy
TemperT1-T5, DR7-DR10
Thickness0.14mm - 0.55mm
Width4.0mm - 1050mm (custom)
Coil ID160mm, 200mm, 300mm, 400mm, 500mm
CertificationsBV ISO9001:2015, SGS REACH & RoHS

Models and Options

  • TP-EC-ZAM-T1 to DR10
  • Coil ID: 160mm to 500mm
  • Coating colors: various, including black, grey, blue

Materials and Structure

The ZAM coating consists of zinc, aluminum, and magnesium, offering outstanding corrosion resistance, including at cut edges. The strip can be supplied with a clear or colored organic coating on one or both sides to enhance corrosion protection and aesthetics.

Applications

Hardware stamping: electronic components, automotive shields, cable wrapping, luggage hardware, and outdoor equipment. Also suitable for home appliances and construction components.

Customization

We can adjust coating weight, temper, width, and coil ID. Contact our team for custom requirements.

FAQ

Q: What is the advantage of ZAM coating?

A: ZAM offers superior corrosion resistance, especially at cut edges, due to the synergistic effect of zinc, aluminum, and magnesium.

Q: Can this material be deep drawn?

A: Yes, with appropriate temper selection (e.g., T1-T3) it offers good formability for deep drawing.

Q: What widths are available?

A: We can slit from 4.0mm to 1050mm width.

Q: Is it REACH and RoHS compliant?

A: Yes, 100% passed SGS REACH & RoHS testing.

Q: What packaging do you provide?

A: Individual protective packaging with anti-moisture barrier.

Inquiry Information

Contact:
Chongqing Youngson Metal Products Co., Ltd.
Tel: 0086-23-62566629
Whatsapp: 0086-13594107385
Email: info@youngsonmetal.com

ZAM alloy coated steel strip with multi-color protective coating for hardware and automotive applications

Image 1: Multi-color coated strip, demonstrating available finishes.

ZAM alloy steel coil with individual protective packaging, BV certified

Image 2: ZAM coated coil in protective packaging.
