Starke 3121 Puzzle Parking System with Pit for Commercial Areas

The Starke 3121 is a semi-automatic puzzle parking system designed for high-traffic commercial environments. With a rated lifting capacity of 2700 kg and the ability to park up to 8 vehicles per unit, it maximizes vertical space in existing pits or underground areas. The hydraulic cylinder and chain drive ensures smooth operation, while the CE certification guarantees compliance with European safety standards.

Key Selling Points

High Capacity: 2700 kg rated lifting capacity per parking space, supporting sedans and SUVs.
Space Efficiency: Parks up to 8 cars in a single unit, optimizing underutilized commercial space.
CE Certified: Complies with 2006/42/EC, EN 14010, EN 60204-1, ensuring safety and reliability.
Hydraulic Drive: Utilizes hydraulic cylinders and chains for smooth, low-noise operation.
Easy Operation: Controlled via code and ID card, providing secure and convenient access.
Customizable Power Supply: Available for 200–450V, 50/60Hz, adaptable to various regions.

Technical Specifications

Vehicles per unit	8
Rated lifting capacity	2700 kg
Allowed car length	5000 mm
Allowed car width	1950 mm
Allowed car height	1700 mm
Drive mode	Hydraulic cylinder + chains
Lifting time	8-12 m/min
Operation	Code & ID card
Power supply	200–450V, 50/60Hz

Models and Options

This variant is specifically the Starke 3121 model. Available configurations include variable arrangements from 8 to 29 cars. Options include centralized hydraulic power unit, remote control, and private labeled logo.

Materials and Structure

Constructed from high-strength carbon steel Q235, ensuring durability and structural integrity. The system features a pit-based design with three vertical levels (-1+2), minimizing above-ground footprint.

Applications

Ideal for commercial parking, underground parking, and high-traffic areas. Successfully implemented in a commercial area in Bucharest, transforming underutilized areas into revenue-generating assets.

Customization

Customization is acceptable. Options include bespoke dimensions, power supply, color, and additional safety features.

Case Study

Commercial Area, Bucharest: Installed a Starke 3121 puzzle parking system with 3 grids wide, accommodating 8 to 29 cars. The system features 2100 kg per parking space, with options for 2700 kg. Minimum pit depth of 1800 mm and ceiling height of 3560 mm. Over 20 safety devices and a transmission safety factor of 7 ensure safe operation.

FAQ

What is the maximum vehicle size?

The allowed car length is 5000 mm, width 1950 mm, and height 1700 mm.

Is the system CE certified?

Yes, the Starke 3121 is CE certified under 2006/42/EC, EN 14010, and EN 60204-1.

What is the minimum pit depth required?

For the case study, a minimum pit depth of 1800 mm was used.

Can the system be used outdoors?

Yes, with an outdoor package option for rust resistance and weather protection.

What is the power supply requirement?

The system supports 200–450V, 50/60Hz, and can be customized to local conditions.

How many parking spaces can be created?

Each unit can hold up to 8 cars, but variable arrangements can provide 8 to 29 cars.

What safety features are included?

The system includes over 20 safety devices, hydraulic synchronization, and anti-fall safety.

Can the system be operated remotely?

Yes, remote control is an available option.

Inquiry Information

For more information or to request a quote, contact us at inquiry@mutrade.com or call +86 532-5557-9606.

Images

Starke 3121 puzzle parking system automated car parking

Starke 3121 puzzle parking system with pit
